Technical Specification
Parameters | Specs |
Panel Size | 43 Inches |
Panel Type | Edge Led Blu |
Resolution | 1920x1080 Fhd (4k If Required) |
Pixel Pitch | 0.2451x0.2451 |
Active Display Area | 941.184 (H)X529.416(V) |
Brightness (Typ.) | 400 (With Touch Glass)Nit |
Contrast Ratio | 5,000:1 (Without Glass) |
Viewing Angle(H/V) | 178/178 |
Response Time(G-To-G) | 8ms(Typ.) |
Display Colours | 16.7m |
Color Gamut | 92% (Dci-P3, Cie 1976) |
Operation Hour | 24/7 |
Haze | 25% (Without Glass) |
Display Dynamic C/R | Mega |
H-Scanning Frequency | 30-81khz |
V-Scanning Frequency | 48-75hz |
Maximum Pixel Frequency | 594mhz |
Speaker Type | Built In Speaker (10w+10w) |
Input Rgb | Dvi-, Display Port 1.2(1) |
Input Audio | Stereo Mini Jack, Dvi, Hdmi |
Input Usb | Usb 2.0x2 |
Input Video | Hdmi 2.0 (2) |
Hdcp | Hdcp2.2 |
Output Rgb | Hdmi 2.0 (Loop-Out) |
Output Audio | Stereo Mini Jack |
Output Usb | Usb Type-Bx2 (Touch Sensor Data, Pc 1/Soc 1) |
External Control | Rs232c(In/Out) Thru Stereo Jack, Rj45 |
External Sensor | Ir |
Power Type | Internal |
Power Supply | Ac 100-240v-(+/-10%),50/60hz |
Key Features | Uhd Signage Display Slim & Light Signage With Built-In Magicinfo S6, Sssp 6.0 Cap Touch |
Orientation | Landscape |
Special Features | H/W: Temperature Sensor, Pivot Display, Clock Battery(168hrs Clock Keeping), Built In Speaker(10w 2ch), Video Wall Daisy Chain (Hdcp2.2:4ea, Hdcp1.47ea), Ip5x Rating, Wi -Fi/Bt S/W: Auto Source Switching & Recovery, Lfd Home Ui, Button Lock, Hot Key Option, Plug & Play (Initial Setting) |
Processor | Cortex A72 1.7ghz Quad-Core Cpu |
Main Memory Interface | 1gb Lpddr4 1.5 Ghz 64bit |
Storage | 8gb (3.88gb Occupied By O/S 4.12gb Available) |
Graphics | Graphic Resolution: 1920x1080 Output Resolution: 3840x2160 (Scale Up From Graphic Processing Unit) |
Io Ports | Usb 2.0 |
Operating System | Zenon |
